Technical Sheets

The following technical data sheets show the various frame types available to suit Pyropanel fire doors including steel frames, 1hr timber frames, Euroseal Frames, and also the methods that are approved to fix frames to various wall types. Information is also provided to show how to rectify excessive gaps around Pyropanel fire doors.

All frames should be built in true and square, and all frames must be sealed back to the fire rated wall using Pyropanel fire rated acrylic sealant (see Passive product range).  Approved wall types include: Masonry, steel and timber stud plaster board, Boral IntRwall Shaftliner systems, Speedpanel Walls, Hebel Walls and Concrete blocks.

Please note that not all doors are approved in every wall type, so please discuss your particular requirements with your local licensed Pyropanel distributor. If you have a wall type that is not listed, or if you require further information on fixing methods, please do not hesitate to contact Pyropanel directly, or any of the licensed Pyropanel distributors listed on this website.
